Set Up Recommendations:

• A PW46 wastegate 234-PBO085-2000J is recommended to effectively control boost.
• Oil should be supplied by a -4 line which is connected to the turbo by 234-PFT047-3039J.
• The recommended oil drain flange is 234-PTP074-2008J and should be connected to a -10 AN oil drain line by fitting 234-PFT047-3009J.
• The PTE specific THV housing will require a V-band turbine inlet flange 234-PTP074-1030J and inlet clamp 234-PTP071-1027J as well as the V-band turbine discharge weld flange 234-PTP074-3050J and discharge clamp 234-PTP071-1029J for manifold and downpipe connections.
• It is always a good idea to cool the boost on with the PTE 750 HP intercooler 234-PIN053-1015J

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.

CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
