PROFORMPART NUMBER: 778-67200-SC
Race Series 750 CFM Draw-Thru Supercharger Gasoline Carburetor w/2-Step Down-Leg Boosters
$92795
1 left in stockSupercharged-Gasoline
Blow-Through Supercharger Carburetor750 CFM Gasoline Boost Reference Power Valve Port 2-Step Down-Leg Boosters Mechanical Secondary Billet Metering Blocks Billet 4150 Throttle Base Plate High-Flow Main Body Aluminum Fuel Bowls
Proform 67200-SC Race Series 750 CFM Gas, Draw-Thru, 2x4 Supercharger Model Carburetor with 2-Step Down-Leg Boosters Features:
- High-flow carburetor main body with no air horn or choke tower
- Billet metering blocks with fuel control baffling, changeable idle feed restriction, and adjustable screw-in air bleeds
- High-performance billet throttle baseplate with adjustable secondary air flow cam bracket, power-valve blow-out protection, slabbed shafts, slip-link mechanical secondary linkage, and serviceable throttle levers
- Aluminum fuel bowls with internal baffles, lower fuel ramp, and sight glass windows
- Timed and full vacuum ports for accessories and tuning
- Uses standard replacement and tuning parts
- Vibratory tumble polished finish
Emissions Note:
This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
CLICK THIS LINK FOR IMPORTANT CARB & EPA EMISSIONS INFORMATION ABOUT THIS PART
Part TypeCarburetor
BrandPROFORM
Package Height7.5
Package Width11.25
Package Length13.5
Weight9.8 PG
Part CategoryPerformance Parts
Primary Power Valve (Hg)4.5 Hg
UsageSupercharged
Primary Discharge Nozzle Size0.031 in (0.8 mm)
Carburetor Type4150 Style Square Flange
ChokeNone
Primary Jet Size76
Carburetor Height3.25 in (82.55 mm)
Carburetor FinishPolished
QuantitySold individually
Primary Inner Air Bleed Sizes Included33
Fuel InletDual
BarrelFour
Cfm750
Supercharged ApplicationYes
Primary Outer Air Bleed Sizes Included70
Secondary Outer Air Bleed Sizes Included70
Secondary Discharge Nozzle Size0.031 in (0.8 mm)
FuelGasoline
Booster TypeDown-leg
Secondary TypeMechanical
Secondary Jet Size87.5
Part FitmentUniversal
Secondary Inner Air Bleed Sizes Included33
Vendor Part Number67200-SC
Package Qty1
Package TypeEA
