Chevy 409 Style Intake Manifold Kit for Cathedral Port Heads
InfoVehicle Info Needed
MODERN CLASSICPART NUMBER: 624-GMLS3022

Chevy 409 Style Intake Manifold Kit for Cathedral Port Heads

$2,11495
ShippingShips on Sep 03, 2026
Lowest PriceLowest Price Guarantee

Chevy 409
Chevy 409 Style Intake Kit
  • LS Cathedral Port Heads
  • Single-Plane Intake Manifold
  • Billet Aluminum Fuel Rails
  • Dual Snorkel, Round Air Cleaner
  • 4150 Carburetor Flange to 92mm Throttle Body Adapter Plate
  • Sold as a Kit

    Breakdown of Included Items

    This GMLS3022 Chevy 409 style intake kit from Modern Classic will give your LS engine retro styling while maintaining modern performance.

    GMLS3022 Features:

    • Single-plane aluminum intake manifold for GM LS III cathedral port cylinder heads
    • -8 AN O-ring black billet aluminum fuel rails for use with LS3 style fuel injectors
    • Dual snorkel round air cleaner in semi-gloss black
    • Adapter plate to go from 4150 intake manifold flange to 4-bolt 92mm drive-by-wire throttle body
    • Compatible with all ECUs and wiring harnesses that support drive-by-wire and speed density tuning
    • Includes all mounting hardware and gaskets for the intake manifold, throttle body, fuel rails, and air cleaner assembly
  • Part TypeIntake Manifold
    BrandMODERN CLASSIC
    Package Height15.0
    Package Width18.0
    Package Length33.0
    Weight41.0 PG
    Part CategoryPerformance Parts
    Wiring Harness IncludedNo
    Throttle Body Bore Size (Mm)92
    UsageStreet/Performance
    Hardware IncludedYes
    Intake MaterialCast Aluminum
    Throttle Body IncludedNo
    Gasket Or Seal IncludedYes
    QuantitySold as a Kit
    Cylinder Head TypeCathedral Port
    Intake FinishNatural
    Injectors IncludedNo
    Fuel Rails IncludedYes
    Intake Manifold IncludedYes
    Engine Make/SizeChevy LS Series
    Injection StyleMulti-port
    Package Qty1
    Package TypeEA
