Features:

• Adjustable from 4-15 psi or 16-65 psi for precise fuel pressure adjustments
• Constructed of billet aluminum with a black anodized base and a clear anodized top for good looks
• Used in systems with a return line back to the tank
• (1) 3/8 NPT Inlet; (1) 3/8 NPT Outlet; and (1) 3/8 NPT Return Port
• Includes fitting for manifold reference
• Includes an 1/8 NPT gauge port
• Boost Reference - 1:1
• For use with gas, diesel and E85 applications

Note: The regulator has a PSI range of 4-15 PSI. It also includes a second spring that can be installed for the 16-65 PSI range. Determine approximate fuel pressure your system will require. If your fuel pressure requirement is between 4 and 15 psi, the factory installed regulator spring is the proper spring. If your fuel pressure requirement is between 16 and 65 psi, insure the pressure adjustment set screw is backed out all the way, remove the 4 cover screws and cover, remove the factory installed spring, replace it with the high pressure spring, and reassemble the regulator.

Emissions Note:

This part is only legal for sale and use on Uncontrolled (Non-Emissions Controlled) Vehicles or on vehicles used solely for the purposes of closed competition racing.
