Vehicle Info NeededFLEX-A-LITEPART NUMBER: 400-117708
Stacked Plate Transmission Cooler Kit with Mounting Bracket
$19199
Ships on Sep 17, 2026
Lowest Price GuaranteeApplication Specific Transmission Coolers
- Stacked Plate Transmission Cooler Kit
- 2003-2007 Ford F-250, F-350 Power Stroke Diesel 6.0L
- 30-Row
- 3/8 in. Hose Barb
- 11 W x 10 H x 0.750 in. D
- Natural Finish
- Includes Aluminum Mounting Bracket, Cooler, Hose, Clamps & Hardware
Durable Trans Cooler for High-Performance Cooling
Flex-A-Lite Advanced Transmission Coolers are designed to provide maximum cooling to demanding engines under the harshest conditions. These coolers are made entirely of aluminum and feature a dimpled plate and fin design to maximize heat transfer while minimizing oil pressure drop. They are available with either -6AN or 3/8-inch barb end fittings.
Part TypeAuto Trans Oil Cooler
Product LineFlex-A-Lite Advanced Transmission Coolers
BrandFLEX-A-LITE
Package Height5.5
Package Width12.5
Package Length17.5
Weight5.245 PG
Part CategoryPerformance Parts
Overall Thickness0.75 in (19.1 mm)
Overall Height11 in (279.4 mm)
Outlet Size0.375 in (9.5 mm)
Inlet Size3/8"
QuantitySold as a kit
Cooler ConstructionPlate
Mounting Kit IncludedYes
Inlet AttachmentHose barb
Cooler FinishNatural
Number Of Cooling Rows30
Outlet AttachmentHose barb
Overall Width10 in (254 mm)
Cooler MaterialAluminum
Vendor Part Number117708
Package Qty1
Package TypeEA
No Questions
No Reviews
Some parts are not legal for use in California or other states with similar laws / regulations
