Vehicle Info NeededCOMP CAMSPART NUMBER: 249-948-1
Hi-Tech Triple Valve Spring O.D.: 1.645"
$3999
Ships on Sep 04, 2026
Lowest Price GuaranteeHi-Tech Triple Valve Springs
- Hi-Tech Triple Valve Spring
- O.D.: 1.645"
- I.D.: .635"
- Seat Load: 332 lbs/in @ 2.100
- Open Load: 950 lbs/in @1.200
- Coil Bind: 1.130"
- Rate: 686 lbs/in.
- 1/pkg.
- Proprietary Alloy
- Maintain Higher Loads
- 1 Year Limited Warranty
Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit
Engine Valve Spring
Part TypeValve Spring
BrandCOMP CAMS
Package Height2.1
Package Width2.8
Package Length4.2
Weight0.35 PG
Part CategoryPerformance Parts
CoatedNo
Coil Bind Height1.13 in (28.702 mm)
Damper Spring IncludedNo
Spring Rate686 lbs./in.
PositionN/A
Open Height1.2 in (30.5 mm)
Open Pressure (Lbs.)949
Installed Pressure (Lbs.)332
QuantitySold individually
Installed Height2.1 in (53.34 mm)
Inside Diameter Of Inner Spring0.635 in (16.129 mm)
Valve Spring StyleStandard
Outside Diameter Of Outer Spring1.645 in (41.8 mm)
Inside Diameter Of Outer Spring1.195 in (30.353 mm)
Inside Diameter0.635 in (16.129 mm)
Spring TypeTriple
Spring Rate (Lbs./In.)686
Outside Diameter1.645 in (41.8 mm)
Number Of Springs Per ValveTriple
Camshaft TypeHydraulic
Vendor Part Number948-1
Package Qty1
Package TypeEA
